TARDIGRADE

PBWP 480

TWO COMPONENT, WATER BASED, POLYURETHANE – BITUMEN WATERPROOFING MATERIAL

Tardigrade PBWP 480 is a polyurethane – bitumen based, two component, low viscosity, water based, cold applied, moisture curing, flexible and elastic waterproofing material.

FIELDS OF APPLICATION

  • Indoor and outdoor
  • In horizontal and vertical applications
  • On flat and inclined roofs
  • Gutters, strainers, eaves and chimney bottoms
  • Under tile applications of wet floors such as bathrooms and kitchens
  • On roofs, terraces and balconies
  • Wet areas in the food, chemical and pharmaceutical industries
  • In concrete and under screed insulation applications

    It is used as a waterproofing material

ADVANTAGES

  • Flexible and elastic It has crack bridging feature
  • It has a very high elongation value
  • Low viscosity
  • Easy application
  • Provides complete water and moisture insulation
  • Breathes
  • Maintains its elasticity at low temperatures
  • Provides complete water and moisture insulation
  • It is successful in overcoat applications

TARDIGRADE

PBWP 480

TWO COMPONENT, WATER BASED, POLYURETHANE – BITUMEN WATERPROOFING MATERIAL

Tardigrade PBWP 480 is a polyurethane – bitumen based, two component, low viscosity, water based, cold applied, moisture curing, flexible and elastic waterproofing material.

FIELDS OF APPLICATION

  • Indoor and outdoor
  • In horizontal and vertical applications
  • On flat and inclined roofs
  • Gutters, strainers, eaves and chimney bottoms
  • Under tile applications of wet floors such as bathrooms and kitchens
  • On roofs, terraces and balconies
  • Wet areas in the food, chemical and pharmaceutical industries
  • In concrete and under screed insulation applications

    It is used as a waterproofing material

ADVANTAGES

  • Flexible and elastic It has crack bridging feature
  • It has a very high elongation value
  • Low viscosity
  • Easy application
  • Provides complete water and moisture insulation
  • Breathes
  • Maintains its elasticity at low temperatures
  • Provides complete water and moisture insulation
  • It is successful in overcoat applications

TARDIGRADE

PBWP 480

TWO COMPONENT, WATER BASED, POLYURETHANE – BITUMEN WATERPROOFING MATERIAL

Tardigrade PBWP 480 is a polyurethane – bitumen based, two component, low viscosity, water based, cold applied, moisture curing, flexible and elastic waterproofing material.

FIELDS OF APPLICATION

  • Indoor and outdoor
  • In horizontal and vertical applications
  • On flat and inclined roofs
  • Gutters, strainers, eaves and chimney bottoms
  • Under tile applications of wet floors such as bathrooms and kitchens
  • On roofs, terraces and balconies
  • Wet areas in the food, chemical and pharmaceutical industries
  • In concrete and under screed insulation applications

    It is used as a waterproofing material

ADVANTAGES

  • Flexible and elastic It has crack bridging feature
  • It has a very high elongation value
  • Low viscosity
  • Easy application
  • Provides complete water and moisture insulation
  • Breathes
  • Maintains its elasticity at low temperatures
  • Provides complete water and moisture insulation
  • It is successful in overcoat applications

APPEARANCE

Color: Black

PACKAGING

  • Part A: 10 kg. net – Part B: 10 kg. net
  • Total Set: 20 kg. net – Total Set: 21,50 kg. gross
  • Part A: 4 kg. net – Part B: 4 kg. net
  • Total Set: 8 kg. net – Total Set: 8,85 kg. gross

STORAGE

Store in original sealed containers in dry environment at temperatures between +10⁰C and +30⁰C. Do not put excessive loads on top of the products, which would damage the packaging.

SHELF LIFE

Shelf life is 9 months from date of production if stored in original unopened containers. Once opened, product should be consumed within same day.

CHEMICAL STRUCTURE

Part A: Bitumen Part B: Polyurethane Resin

APPEARANCE

Color: Black

PACKAGING

  • Part A: 10 kg. net – Part B: 10 kg. net
  • Total Set: 20 kg. net – Total Set: 21,50 kg. gross
  • Part A: 4 kg. net – Part B: 4 kg. net
  • Total Set: 8 kg. net – Total Set: 8,85 kg. gross

STORAGE

Store in original sealed containers in dry environment at temperatures between +10⁰C and +30⁰C. Do not put excessive loads on top of the products, which would damage the packaging.

SHELF LIFE

Shelf life is 9 months from date of production if stored in original unopened containers. Once opened, product should be consumed within same day.

CHEMICAL STRUCTURE

Part A: Bitumen Part B: Polyurethane Resin

APPEARANCE

Color: Black

PACKAGING

  • Part A: 10 kg. net – Part B: 10 kg. net
  • Total Set: 20 kg. net – Total Set: 21,50 kg. gross
  • Part A: 4 kg. net – Part B: 4 kg. net
  • Total Set: 8 kg. net – Total Set: 8,85 kg. gross

STORAGE

Store in original sealed containers in dry environment at temperatures between +10⁰C and +30⁰C. Do not put excessive loads on top of the products, which would damage the packaging.

SHELF LIFE

Shelf life is 9 months from date of production if stored in original unopened containers. Once opened, product should be consumed within same day.

CHEMICAL STRUCTURE

Part A: Bitumen Part B: Polyurethane Resin

TECHNICAL SPECIFICATIONS

All technical values were calculated based on +23⁰C and 50% relative humidity. Temperature and humidity changes would change technical values.

Density

Mixed Resin: 1,05 kg/litre (± %3)

Viscosity

Mixed Resin: 1.000 – 2.000 mPa.s

Shore A Hardness

7 days: 50 – 70 (ASTM D2240-05)

Bond Strength

7 days: > 1 N/mm² (Concrete) (ASTM D7234)

Solid Matter Ratio

~60%

Elongation at Break

7 days: > 1000 (ASTM D 638)

Duration of Use After Mixing

30 – 50 minutes

Total Curing Time

7 days

TECHNICAL SPECIFICATIONS

All technical values were calculated based on +23⁰C and 50% relative humidity. Temperature and humidity changes would change technical values.

Density

Mixed Resin: 1,05 kg/litre (± %3)

Viscosity

Mixed Resin: 1.000 – 2.000 mPa.s

Shore A Hardness

7 days: 50 – 70 (ASTM D2240-05)

Bond Strength

7 days: > 1 N/mm² (Concrete) (ASTM D7234)

Solid Matter Ratio

~60%

Elongation at Break

7 days: > 1000 (ASTM D 638)

Duration of Use After Mixing

30 – 50 minutes

Total Curing Time

7 days

TECHNICAL SPECIFICATIONS

All technical values were calculated based on +23⁰C and 50% relative humidity. Temperature and humidity changes would change technical values.

Density

Mixed Resin: 1,05 kg/litre (± %3)

Viscosity

Mixed Resin: 1.000 – 2.000 mPa.s

Shore A Hardness

7 days: 50 – 70 (ASTM D2240-05)

Bond Strength

7 days: > 1 N/mm² (Concrete) (ASTM D7234)

Solid Matter Ratio

~60%

Elongation at Break

7 days: > 1000 (ASTM D 638)

Duration of Use After Mixing

30 – 50 minutes

Total Curing Time

7 days
